(1) Phenolic Resin countertop: 12.7mm (Edge banding and Thicken to 25.4mm)/16~30mm thickness
(2) Epoxy Resin countertop:16/19/20/25mm thickness
(3) Ceramic countertop: 20mm thickness
(4) Trespa countertop: 13/16/19/20/25mm thickness
(5) Granite/Marble countertop: 20mm thickness
(1) Frame: The whole adopts 40*60*1.5mm thick high-quality cold-rolled rectangle tube, the steel surface is treated, phosphating and other processes, and then electrostatic powder coated with epoxy resin, cured at 220°C high temperature, and the surface is smooth.
(2) Handle: Aluminum alloy/Non-welded linear handle/C-shaped handle/Insertion Aluminum alloy handle.
(3) Rail: DTC 16-inch three-section silent rail.
(4) Hinge: DTC 105°/175° buffer hinge/stainless steel hinge.
(5) Footing: Use laboratory-specific adjustable feet with an adjustment range of ≥35mm, strong bearing capacity, the balance of the Lab bench can be adjusted.
Option Cabinet Unit
①Wooden Cabinet Unit:
The cabinet body thickness is 15mm, the door and drawer panels are made of 18mm thickness high-quality environmentally friendly double-face MDF/melamine board, and the edges are sealed with 2mm thick PVC edge strips. The edges are firm, clean, and free of burrs, the bond is firm.
②Steel Cabinet Unit:
1.0mm full-thickness high-quality cold-roll steel sheet is used as a whole; the steel surface is treated, phosphating and other processes, and then electrostatic powder coated with epoxy resin, cured at 220°C high temperature, and the surface is smooth, with a thickness of up to 1.15mm~1.2mm. The cabinet door is double-layered inside and outside, filled with sound insulation material.
