Ducted Fume Hood
Created with Pixso.

6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee

6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee

Brand Name: SUCLAB
Model Number: HZJT008
MOQ: 1 SET
Price: Negociation
Payment Terms: EXW,T/T, D/A, Western Union, MoneyGram
Supply Ability: 10000 Sets/ Month
Detail Information
Place of Origin:
CHINA
Certification:
ISO9001,14001,CE
Ventilation System:
Ducted
Control System:
Microcomputer Control
Control Method:
Manual/Automatic
Color:
White
Control Panel:
Digital
Safety System:
Automated
Filter:
HEPA
Window:
6 Mm Temperated Glass
Wind Speed:
0.3-0.6m/s
Controls:
Touchscreen
Capacity:
100-1000 CFM
Lighting System:
LED
Filter Efficiency:
99.99%
Size:
1200mm/1500mm/1800mm
Wind Pressure:
200Pa
Noise:
≤65dB
Air Volume:
1000m3/h
Humidity:
≤80%
Work Surface:
Chemical-resistant Work Surface
Lighting Intensity:
1000Lux
Packaging Details:
Export Plywood Package
Supply Ability:
10000 Sets/ Month
Highlight:

Ducted Lab Fume Hood

,

Microcomputer Control System Lab Fume Hood

Product Description

6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee

Product Description:

Ducted Fume Hood

A ducted fume hood is an essential piece of equipment used in laboratory settings to protect researchers from harmful fumes, gases, and vapors. It works by drawing in air from the laboratory and expelling it outside, thus preventing the buildup of hazardous substances in the workspace. This type of fume hood is commonly used in chemical, pharmaceutical, and biological research facilities.

Window: 6mm Tempered Glass

The ducted fume hood is equipped with a 6mm tempered glass window, providing a clear view of the workspace while ensuring durability and safety. The glass is resistant to heat, chemicals, and impacts, making it suitable for use in a laboratory environment.

Alarm System: Audible and Visual Alarms

Safety is a top priority in laboratory settings, and that's why the ducted fume hood is equipped with audible and visual alarms. These alarms will be triggered if there is a sudden change in airflow, indicating a possible leak or malfunction. This feature ensures the safety of researchers and the laboratory environment.

Control Panel: Digital

The control panel of the ducted fume hood is designed with advanced digital technology, allowing for precise and easy control of airflow and other functions. This digital control panel also displays important information such as air velocity, filter life, and operating status, providing researchers with real-time feedback.

Light: LED

The ducted fume hood is equipped with energy-efficient LED lights, providing bright and even lighting for the workspace. These lights have a longer lifespan and consume less energy compared to traditional fluorescent lights, reducing operating costs and environmental impact.

Sash Type: Vertical Sliding

The sash of the ducted fume hood is designed to slide vertically, allowing for easy adjustment of the opening size. This feature not only provides flexibility for different experiment setups but also ensures the safety of researchers by maintaining a constant airflow velocity.

Ducted Lab Fume Hood Supply

As a leading manufacturer and supplier of laboratory equipment, we provide top-quality ducted lab fume hoods to meet the specific needs of different research facilities. Our fume hoods are designed with the latest technology and strict quality control, ensuring the safety and efficiency of your laboratory operations.

What is a Lab Ducted Fume Hood?

A lab ducted fume hood is a ventilation system used in laboratory settings to control and expel hazardous fumes, gases, and vapors. It is essential for protecting researchers and maintaining a safe and healthy working environment.

Ducted Lab Fume Hoods Quotation

For a personalized quotation on our ducted lab fume hoods, please contact us with your specific requirements. We are committed to providing competitive prices and excellent customer service to meet all your laboratory equipment needs.



Features:

  1. Product Name:Ducted Lab Fume Hood Manufacturer
  2. Control Method: Manual/Automatic
  3. Gurrantee: 1 Year
  4. Control System: Microcomputer Control
  5. Sash Type: Vertical Sliding
  6. Filter: HEPA
  7. Suppliers: Ducted Lab Fume Hood Suppliers
  8. Manufacturers: Ducted Lab Fume Hood Manufacturers
  9. Application: Chemistry Lab Ducted Fume Hood


Technical Parameters:

Product Name Ducted Lab Fume Hood Manufacturer
Brand SUCLAB
Model BL-DH-A/B/C/D
Color White
Alarm System Audible And Visual Alarms
General Use Commercial Furniture
Exhaust System Ducted
Gurrantee 1 Year
Sash Type Vertical Sliding
Control Method Manual/Automatic
Safety System Automated
Air Volume 1000m3/h
Window 6 Mm Temperated Glass
Key Features Biobase Ducted Lab Fume Hood, Ducted Lab Fume Hood USA, Ducted Lab Fume Hood Manufacturer

6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 0
1.Hood body&base cabinet:1.0mm full thickness 304#/316# stainless steel sheets and the surface is smooth.
2.Standard Work Surface: Stainless Steel. Optional: Phenolic Resin/Epoxy Resin/PP/Ceramic/Trespa/Granite/Marble. 3.Controller: Intelligent switch with digital display, multiple controls such as power on, fan, lighting, socket, sterilization, damper, etc.. 4.Glass sash: Use explosion-proof 5mm tempered glass, stainless steel sash handle. It is designed by the weight balance method in the mechanical principle, and the left and right are connected by synchronous wheels. 5.Lighting: Equipped with LED 30W purification lamp, the luminosity is greater than 300LUX. 6. Fume hood liner and Baffle: Use stainless steel sheets. 7. Junction box: The junction box with circuit board and AC contactor makes wiring more convenient. Suitable for 110V-230V voltage. 8. Standard accessories: 1x bench-mounted single water tap 1x PP oval cupsink 4x Electrical Outlets 1x 250 or 315mmφ stainless steel hood. 9.Optional accessories: Remote Controlled Fixture gas&water faucet Explosion-proof light Stainless steel distillation Grid Kit Acid and flammable base cabinet Ductwork Exhaust blower
Model
HZJ-120
HZJ-150
HZJ-180
External Dimension
(W*D*H)(mm)
1200*850*2350
1500*850*2350
1800*850*2350
Internal Dimension
(W*D*H)(mm)
960*680*1150
1260*680*1150
1560*680*1150
Base Cabinet Dimension
(W*D*H)(mm)
1200*800*850
(Can remove)
1500*800*850
(Can remove)
1800*800*850
(Can remove)
Exhaust air volume
700-1300m³/h
900-1700m³/h
1300-2100m³/h
Air Velocity
0.3~0.8 m/s
6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 1
6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 2
6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 3
6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 4
6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 5




Cabinet Material
1.0mm full thickness 304#/316# stainless steel sheets and the surface is smooth.




Junction box
The junction box with circuit board and AC contactor makes wiring more convenient. Suitable for 110V-230V voltage.
6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 6
6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 7




Controller
Intelligent touch screen with digital display, multiple controls such as power on, fan, lighting, socket, sterilization, damper, etc.






Electric Outlet
Each national standard electric outlet is available
6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 8

Applications:

Brand Name: SUCLAB
Model Number: HZJT008
Place of Origin: CHINA

The SUCLAB HZJT008 Ducted Lab Fume Hood Manufacturer is a top-of-the-line laboratory equipment designed to provide a safe and efficient working environment for scientists, researchers, and professionals. With its exceptional features and reliable performance, it has become a go-to choice for many laboratories across the world.

Window: 6 Mm Temperated Glass

The ducted fume hood is equipped with a tempered glass window that provides a clear view of the working area and ensures maximum safety for users. The window is 6mm thick, making it durable and resistant to chemicals and other hazardous substances.

Gurrantee: 1 Year

SUCLAB takes pride in providing high-quality products that meet the industry standards. That's why the HZJT008 ducted fume hood comes with a 1-year guarantee, giving you peace of mind and assurance of its quality and performance.

Ventilation System: Ducted

The ducted lab fume hood is designed with a powerful ventilation system that effectively removes harmful fumes, vapors, and gases from the working area. The ducted system ensures that the air is safely directed outside the laboratory, maintaining a clean and safe environment for users.

Safety System: Automated

Safety is a top priority in any laboratory setting, and the SUCLAB HZJT008 ducted fume hood is built with an automated safety system to ensure maximum protection for users. The system includes features such as an alarm for any abnormalities, automatic shut-off in case of power failure, and sensors for air flow and pressure.

General Use: Commercial Furniture

The ducted fume hood is designed to cater to the needs of various industries, including pharmaceutical, chemical, and research laboratories. It is a must-have piece of furniture for any commercial laboratory, providing a safe and efficient working environment for professionals.

With its exceptional features and reliable performance, the SUCLAB HZJT008 ducted fume hood is the ideal choice for any laboratory seeking a high-quality and efficient solution for handling hazardous substances. Made with the best materials and advanced technology, it guarantees a safe and productive working environment for all users.



Customization:

SUCLAB - HZJT008 Ducted Lab Fume Hood Manufacturer Customization Service

Brand Name: SUCLAB

Model Number: HZJT008

Place of Origin: CHINA

Sash Type: Vertical Sliding

Control Panel: Digital

Color: White

Light: LED

Alarm System: Audible And Visual Alarms

At SUCLAB, we understand the importance of having a customizable ducted lab fume hood for your laboratory needs. That's why we offer a range of customization options for our HZJT008 model to ensure it meets your specific requirements.

Our ducted lab fume hood is made of high-quality materials, ensuring durability and reliability in your lab. As a leading manufacturer of ducted lab fume hoods, we ensure that our products meet international safety standards and regulations.

With our biobase ducted lab fume hood, you can rest assured that your lab environment will remain clean and safe. Our hood is designed to effectively remove hazardous fumes and chemicals, providing a safe working environment for you and your team.

Our HZJT008 model features a vertical sliding sash type, allowing for easy and precise adjustment of the sash height. The digital control panel allows for precise control of airflow and other settings, providing you with a customizable and efficient working environment.

The white color of our ducted lab fume hood gives a clean and professional look to your lab space. The LED light provides ample illumination for your work, reducing eye strain and increasing productivity.

We understand the importance of safety in the lab, which is why our HZJT008 model comes with audible and visual alarms to alert you of any potential hazards or malfunctions. This feature gives you peace of mind while working in the lab.

Choose SUCLAB for all your ducted lab fume hood customization needs. Our commitment to quality and customer satisfaction makes us the preferred choice for researchers and scientists worldwide.



Packing and Shipping:

Packaging and Shipping for Ducted Lab Fume Hood Manufacturer

Our Ducted Fume Hood is carefully packaged to ensure safe and secure delivery to our customers. Each unit is wrapped in protective materials and placed in a sturdy, double-walled cardboard box. Inside the box, the fume hood is further secured with foam padding to prevent any damage during shipment.

For shipping, we have partnered with reputable and reliable courier services to ensure timely delivery of our product. The fume hood is shipped with insurance to cover any potential damages during transit.

Upon receiving the package, customers are advised to inspect the fume hood for any damages or defects. In the unlikely event of any issues, our customer service team is available to assist and provide a solution.

We also offer international shipping for our Ducted Fume Hood. Please contact us for more information and shipping rates to your location.

Thank you for choosing our Ducted Fume Hood. We are committed to providing quality products and excellent customer service.



6 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 96 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 106 Mm Temperated Glass Ducted Lab Fume Hood Manufacturer Microcomputer Control System 1 Year Gurrantee 11
