DTC Lab Benches Silent Rail 16-Inch Three Sections for OEM ODM
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | SUCLAB |
| Certification: | ISO9001, ISO14001 |
| Model Number: | HZJT006 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 SETS |
|---|---|
| Price: | Negociation |
| Packaging Details: | Export Plywood Package |
| Delivery Time: | 15 Days |
| Payment Terms: | T/T, D/A, L/C, D/P, MoneyGram |
| Supply Ability: | 10000 Sets /Month |
|
Detail Information |
|||
| Hinge: | DTC 105°/175° Buffer Hinge/stainless Steel Hinge | Counter Tops: | Phenolic/Epoxy Resin Board/Ceramic/Stainless Steel / Trespa/Granite /Marble |
|---|---|---|---|
| Faucet: | Brass Body With Ceramic Valve Core, Coating With Epoxy Powder Coating | Reagent Racks: | Frame:40*60*100mm Cold-rolled Steel Coated With Epoxy Resin Powder.with 12mm Thick Adjustalbe Glass Shelf |
| Rail: | DTC 16-INCH THREE SECTION SILENT RAIL | Handle: | Non-welded Linear Handle/C-shared Handle/ Insertion Aluminum Alloy Handle |
| Sink: | PP /ceramic /epoxy Resin Sink | Base Cabinet: | Wooden /steel Cabinet |
| Color: | White | Design: | Modern |
| Function: | Chemistry Experiment | Material: | Steel |
| Name: | Chemistry Lab Bench | Origin: | China |
| Packaging: | Wood | Surface Treatment: | Powder Coating |
| Warranty: | 1 Year | Weight: | 80 Kg |
Product Description
DTC Lab Benches Silent Rail 16-Inch Three Sections for OEM ODM
Product Description:
The Chemistry Lab Bench offers a sophisticated and reliable solution for chemical laboratory furniture. This workstation features a 16-inch three-section silent rail, a PP/ceramic/epoxy resin sink, and a non-welded linear handle/C-shared handle/insertion aluminum alloy handle. The dimensions of the bench can be customizable to fit any laboratory space. Additionally, the faucet is made of a brass body with ceramic valve core, and is coated with epoxy powder coating.
This bench is designed to meet the highest quality standards for chemical laboratory furniture and lab caseworks. The robust construction and materials used make it a dependable and long-lasting option for laboratory spaces. It is also designed to be easy to maintain and clean, making it the perfect choice for any lab.
The Chemistry Lab Bench is a reliable and sophisticated solution for any chemical laboratory. It is designed to provide a durable and safe workstation, while making it easy to maintain and clean. With customizable dimensions and high-quality materials, this bench will be a dependable addition to any laboratory.
Specification :
| Worktop: | Phenolic/Epoxy resin board/Ceramic/Stainless steel / Trespa |
| Colour: | Grey,light gray,blue,yellow,black,white ect |
| Dimension: | L*1500/750(W) *850 /900mm(H) or customizable |
| Structure | C-Frame/H-Frame/Floor Mounted |
| Base cabinet: | Main body: 1.0/1.2mm thick durable and chemical resistant cabinets ,electrostatic epoxy powder spraying.Double panels doors and drawers. Full height removable back provides full access to service chase,stainless steel hardware |
| Adjustable Shelf: | Adjustable shelf with maximum storage length |
| Reagent racks: | Frame:40*60*100mm cold-rolled steel coated with epoxy resin powder.with 12mm thick adjustalbe glass shelf |
| Faucet: | Brass body with ceramic valve core |
| Sink: | PP sink;ceramic sink; epoxy resin sink |
| Socket: | Multi-functional /customized |
| Applied range | Goverment, hospital, school, industry lab etc |
| Server type: | OEM & ODM |
Optional
(1) Reagent shelf:
The main frame is made of cold-rolled steel with 1.5mm thickness, coated with epoxy powder.
The shelf is made of reinforce glass with 12mm thickness and stainless steel tube to be guardrail. The shelves can be adjustable.
(2) Choices of sink: PP sink or FRP sink.
(3) Choices of pegboard and pegstick as blow:
A. Pegboard and pegstick, both made of PP.
B. Pegboard, made of solid core physiochemical board; pegstick, made of PP.
(4) Three outlet cold water faucet: with international ceramic valve core featured to slow down water pressure. The surface is coated with epoxy resin power.
(5) Socket box: free standing socket with safeguard cover. It can apply to any instrument’s plugs.
| Composition | Max. Long term Heat Resistance | Chemical Resistance | Chemical Weaknesses | |
| Ceramic | Natural Silicate | 800°C | Strong resistance against solvents, bases, oxidants and most acids | Hydrofluoric acid |
| Epoxy Resin | Epoxy resin, silica, hardener, pigment | 300°C | Strong resistance against solvents, bases, and most oxidants | Sulfuric acid, nitric acid, hydrofluoric acid, potassium permanganate |
| Phenolic Resin Laminate | Chemical resistant film, overlay paper, deco paper, Kraft paper | 135°C | Strong resistance against solvents, oxidants, and many acids | Sulfuric acid, nitric acid, sodium hydroxide |
| Toplab Plus® | Refined wood fiber, hydroxybenzen, aldehyde resin | 180°C | Strong resistance against solvents, bases, and oxidants | Hydrofluoric acid |
| Stainless Steel | Stainless steel,Melamine board | 180°C | Strong resistance against solvents, bases, oxidants, and organic acids | Mineral acids (hydrochloric, sulfuric, nitric, phosphoric, hydrofluoric) |
| Polypropylene | Propylene, ethylene | 110°C | Strong resistance against bases and most oxidants, Hydrofluoric acid | Toluene, hydrochloric acid, nitric acid, formic acid, potassium dichromate |
Features:
- Product Name: Chemistry Lab Bench
- Material: Steel Wood/full Steel /304 Stainless Steel/PP /...
- Hinge: DTC 105°/175° Buffer Hinge/stainless Steel Hinge
- Rail: DTC 16-INCH THREE SECTION SILENT RAIL
- Counter tops: Phenolic/Epoxy Resin Board/Ceramic/Stainless Steel / Trespa/Granite /Marble
- Faucet: Brass Body With Ceramic Valve Core, Coating With Epoxy Powder Coating
- Keywords: laboratory casework manufacturers, lab workbench with drawer, science lab furniture
Technical Parameters:
| Parameter | Description |
|---|---|
| Counter tops | Phenolic/Epoxy Resin Board/Ceramic/Stainless Steel/Trespa/Granite/Marble |
| Shape | Rectangular Or Customized |
| Faucet | Brass Body With Ceramic Valve Core, Coating With Epoxy Powder Coating |
| Handle | Non-welded Linear Handle/C-shared Handle/ Insertion Aluminum Alloy Handle |
| Applied range | Goverment, Hospital, School, Industry Lab Etc |
| Hinge | DTC 105°/175° Buffer Hinge/stainless Steel Hinge |
| Dimension | L*1500/750(W) *800 /850mm(H) Or Customizable |
| Material | Steel Wood/full Steel /304 Stainless Steel/PP/... |
| Sink | PP/ceramic/epoxy Resin Sink |
| Base cabinet | Wooden/steel Cabinet |
Applications:
The SUCLAB HZJT006 Chemistry Lab Bench is a perfect solution for chemical laboratory casework, laboratory bench, laboratory furniture, lab bench, and lab furniture. It is made with high quality materials and certified with ISO9001 and ISO14001, ensuring its quality and safety. It is available in a rectangular shape or customized shape with a sink made of PP, ceramic, or epoxy resin. It also comes with a non-welded linear handle, C-shared handle, or insertion aluminum alloy handle. The counter tops are made of phenolic/epoxy resin board, ceramic, stainless steel, Trespa, granite, or marble. The reagent racks are made of frame with 40*60*100mm cold-rolled steel coated with epoxy resin powder, 12mm thick adjustable glass shelf.
The minimum order quantity for the SUCLAB HZJT006 Chemistry Lab Bench is 10 sets. The price is negotiable and the delivery time is 15 days. Payment terms are available through T/T, D/A, L/C, D/P, or MoneyGram. Its supply ability is 10000 sets per month and it comes with an export plywood package.
Customization:
This chemistry lab bench, made from SUCLAB, is the perfect choice for all your science lab workstation needs. It has been certified with ISO9001 and ISO14001, so you can be sure it meets the highest standards. The minimum order quantity is 10 sets. The price is negotiable. It comes with an export plywood package and will be delivered in 15 days. You can pay via T/T, D/A, L/C, D/P, MoneyGram. We have a supply ability of 10000 sets/month.
The shape of the chemistry lab bench is either rectangular or customizable. It has a multi-functional socket with a splash-proof box and safeguard cover, or it can be customized. The handle can be non-welded linear handle, C-shared handle, or an insertion aluminum alloy handle. The dimension is L*1500/750(W) *800 /850mm(H) or customizable. We offer OEM and ODM services.
Support and Services:
- Remote technical support for installation and setup
- On-site installation and setup
- Product training and demonstration
- Product upgrades and maintenance services
- Troubleshooting and repair
- Replacement parts and consumables
- Data backup and recovery services
Packing and Shipping:
The Chemistry Lab Bench is packaged with a strong cardboard box and protected with foam. The box should be labeled with "This Side Up" signs to ensure that the bench is not damaged during the shipping process. The box should then be sealed with packing tape.
The box can be shipped via any shipping carrier, such as UPS, FedEx, or DHL. Please refer to the shipping carrier's guidelines for packing and shipping.
FAQ:
A1: The brand name of the Chemistry Lab Bench is SUCLAB.
A2: The model number of the Chemistry Lab Bench is HZJT006.
A3: The Chemistry Lab Bench is manufactured in China.
A4: The Chemistry Lab Bench has ISO9001 and ISO14001 certifications.
A5: The minimum order quantity for the Chemistry Lab Bench is 10 sets
