Ducted Fume Hood
>
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation

Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation

Product Details:
Place of Origin: CHINA
Brand Name: SUCLAB
Certification: ISO9001,14001
Model Number: HZJT006
Detail Information
Place of Origin:
CHINA
Brand Name:
SUCLAB
Certification:
ISO9001,14001
Model Number:
HZJT006
Installation:
Wall Mounted
Power:
1.5KW
Airflow:
2500m3/h
Certificate:
ISO9001
Color:
Silver
Control System:
PLC
Display System:
Touch Screen
Lighting System:
LED
Material:
Stainless Steel
Noise Level:
≤65dB
Product Name:
Ducted Fume Hood
Safety System:
Alarm
Size:
Customized
Voltage:
220V
Warranty:
1 Year
Trading Information
Minimum Order Quantity:
1 SET
Price:
Negociation
Packaging Details:
Export Plywood Package
Delivery Time:
15 days
Payment Terms:
EXW,T/T, D/A, Western Union, MoneyGram
Supply Ability:
10000 Sets/ Month
Product Description

Stainless Steel Laboratory Fume Cupboards with LED Lighting for Improved Ventilation

Product Specification:

Ducted Fume Hood is a laboratory fume cupboard designed to provide operators with safe and efficient working environment. It is available in several sizes (1200*850*2350 Mm, 1599*850*2350mm, 1800*850*2350 Mm) and features auto shut-off which can be triggered when safety is compromised. It is wall mounted and comes with a one year warranty. It is designed to work with 110V/220V voltage. Ducted Fume Hood is a perfect choice for safe and efficient laboratory safety.



Technical Parameters:

Property Value
Control System Electronic
Maintenance Regular
Product Name Ducted Fume Hood
Warranty 1 Year
Voltage 110V/220V
Material Stainless Steel
Safety Features Auto Shut-off
Power 400W
Lighting LED
Installation Wall Mounted
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 0
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 1
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 2
1.Hood body&base cabinet:1.0mm full thickness 304#/316# stainless steel sheets and the surface is smooth.
2.Standard Work Surface: Stainless Steel. Optional: Phenolic Resin/Epoxy Resin/PP/Ceramic/Trespa/Granite/Marble. 3.Controller: Intelligent switch with digital display, multiple controls such as power on, fan, lighting, socket, sterilization, damper, etc.. 4.Glass sash: Use explosion-proof 5mm tempered glass, stainless steel sash handle. It is designed by the weight balance method in the mechanical principle, and the left and right are connected by synchronous wheels. 5.Lighting: Equipped with LED 30W purification lamp, the luminosity is greater than 300LUX. 6. Fume hood liner and Baffle: Use stainless steel sheets. 7. Junction box: The junction box with circuit board and AC contactor makes wiring more convenient. Suitable for 110V-230V voltage. 8. Standard accessories: 1x bench-mounted single water tap 1x PP oval cupsink 4x Electrical Outlets 1x 250 or 315mmφ stainless steel hood. 9.Optional accessories: Remote Controlled Fixture gas&water faucet Explosion-proof light Stainless steel distillation Grid Kit Acid and flammable base cabinet Ductwork Exhaust blower
Model
SSFH-120
SSFH-150
SSFH-180
External Dimension
(W*D*H)(mm)
1200*850*2350
1500*850*2350
1800*850*2350
Internal Dimension
(W*D*H)(mm)
960*680*1150
1260*680*1150
1560*680*1150
Base Cabinet Dimension
(W*D*H)(mm)
1200*800*850
(Can remove)
1500*800*850
(Can remove)
1800*800*850
(Can remove)
Exhaust air volume
700-1300m³/h
900-1700m³/h
1300-2100m³/h
Air Velocity
0.3~0.8 m/s
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 3
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 4
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 5
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 6
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 7
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 8
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 9




Cabinet Material
1.0mm full thickness 304#/316# stainless steel sheets and the surface is smooth.




Junction box
The junction box with circuit board and AC contactor makes wiring more convenient. Suitable for 110V-230V voltage.
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 10
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 11




Controller
Intelligent touch screen with digital display, multiple controls such as power on, fan, lighting, socket, sterilization, damper, etc.






Electric Outlet
Each national standard electric outlet is available
Stainless Steel Ducted Fume Hood with LED Lighting for Improved Ventilation 12

Applications:

SUCLAB's HZJT006 Ducted Fume Hood

The SUCLAB HZJT006 Ducted Fume Hood is a laboratory fume cupboard designed to provide maximum safety and protection for personnel when working with hazardous chemicals and materials. It features an electronic control system, which allows for easy and precise adjustment of the flow rate of air into the hood. The ducted fume hood also includes a wall-mounted installation option to provide user flexibility. For added safety, it is equipped with an auto shut-off system that will immediately shut down the system if the air flow is interrupted or if the temperature within the fume hood exceeds the set safety levels. The hood comes with a 1-year warranty to ensure reliable performance and maintenance.

The SUCLAB HZJT006 Ducted Fume Hood is ideal for use in chemical laboratories, pharmaceutical industries, and other areas where hazardous materials are handled. It is a reliable and efficient piece of laboratory safety equipment that can help keep personnel safe and protected.



Customization:

Product Attributes:
  • Brand Name: SUCLAB
  • Model Number: HZJT006
  • Place of Origin: CHINA
  • Control System: Electronic
  • Safety Features: Auto Shut-off
  • Warranty: 1 Year
  • Maintenance: Regular
  • Power: 400W

SUCLAB Ducted Fume Hood is specially designed for laboratory fume cupboards. It is equipped with advanced electronic control system and auto shut-off safety features for maximum safety. It offers a 1-year warranty and regular maintenance for maximum durability. With 400W of power, it is ideal for laboratory use.



Support and Services:

Technical Support and Service for Ducted Fume Hood

We provide technical support and service for Ducted Fume Hood. Our team of experts can help you choose the right product, install it properly, and provide ongoing maintenance and repair services. We also provide emergency services 24/7, so you can rest assured that we'll be there when you need us. Our team is highly trained and experienced in troubleshooting and repairing all types of Ducted Fume Hoods.

We strive to provide the best customer service possible and guarantee all of our work. If you have any questions or concerns about Ducted Fume Hoods, please don't hesitate to contact us. We look forward to working with you.



Packing and Shipping:

Packaging and Shipping for Ducted Fume Hood

The Ducted Fume Hood will be shipped in a single package. It will be securely packaged to protect it during the transit. It will be shipped on a pallet, with the package being shrink-wrapped to the pallet.

In order to ensure safe transit, the Ducted Fume Hood will be secured to the pallet with straps or other suitable packing materials. The package will be clearly labeled with the shipping address and the weight of the package.



FAQ:

Q1: What is Ducted Fume Hood?

A1: Ducted Fume Hood is a fume hood designed to contain and exhaust hazardous or noxious fumes and vapors generated by laboratory processes. The SUCLAB HZJT006 model is made in China.

Q2: What are the advantages of a Ducted Fume Hood?

A2: Ducted Fume Hoods provide protection to the laboratory personnel from hazardous vapors, fumes, and dusts in the laboratory environment. It also helps to maintain a safe working environment with good indoor air quality.

Q3: How does a Ducted Fume Hood work?

A3: A Ducted Fume Hood is designed to capture and remove hazardous vapors, fumes, and dusts from the laboratory. It draws in the contaminated air through the front opening and passes it through a filter before discharging it outside the building.

Q4: What are the features of SUCLAB HZJT006 Ducted Fume Hood?

A4: SUCLAB HZJT006 Ducted Fume Hood features an adjustable airflow control system, a high-efficiency air filter, an adjustable sash system, and a built-in alarm system.

Q5: What safety measures should be taken when operating a Ducted Fume Hood?

A5: When operating a Ducted Fume Hood, it is important to ensure that the sash is closed when not in use, the filter is cleaned regularly, and that the alarm system is checked and maintained for optimal performance.
